Custom GHCL IP65 Led bulkhead

Home / Product / IP65 LED Triproof light / GHCL IP65 Led bulkhead

GHCL IP65 Led bulkhead


Product Description

Model D(mm) H(mm) LF(mm)
GH220CL 220 60
GH280CL 1150 65
GH330CL 1450 68

Code Input Voltage Output power LED CCT CRI LED quantity Luminous flux  IK IP Rating Dimensions mm
Line Rating H LF
GH220CL 220-240V  50/60HZ 1 PCB 10W 2835 3000K-6500K ≥80 64 1000lm 08 65 220 60 210
GH280CL 220-240V  50/60HZ 1 PCB 20W 2835 3000K-6500K ≥80 128 2000lm 08 65 280 65 270
GH330CL 220-240V  50/60HZ 1 PCB 24W 2835 3000K-6500K ≥80 136 2400lm 08 65 330 68 350

Spec:1.IP65 LED bulkhead
         2.PC base with Opal PC diffuser
         4.100 Lumen/Watt

Option:1.Emergency Kits

Ningbo Fenghua Lamp Co., Ltd.

In Zhangqi town , Cixi, China, bordering east and famous Beilun port, west to the world’s longest Hangzhou Bay Bridge, is connected with the sea and air transportation is convenient. Ningbo Fenghua Lamp Co.,Ltd is professional GHCL IP65 Led bulkhead manufacturers and GHCL IP65 Led bulkhead suppliers in China. FengHua lighting have owned R&D team, complete production line and strict quality control system and sales team. For customer’s requirements, company is certificated by ISO9001 and ISO14001. All of our products have been approved by CE, CB ,SAA, etc. Company adhering to the“dedicated, win-win beyond” as operation policy, hope to go green and environmental lighting in future is our goals, Fenghua, Light your life.
